| 20-FT Standard Wood Grain Double-Wing Expansion House Technical Parameters | ||
|---|---|---|
| Basic Information | Expanded size (mm) L*W*H | L5900*W6300*H2480 |
| Internal space (mm) L*W*H | L5640*W6140*H2240 | |
| Folded size (mm) L*W*H | L5900*W2200*H2480 | |
| Weight (KG) | 2500 | |
| Framework | Main beam | Galvanized square tube 80*100*2.5MM Q235 |
| Integrated column head | Galvanized folding piece 150*210*2.0MM Q235 | |
| Sub-frame | Galvanized square tube 40*60*1.0MM Q235 | |
| Hinges | Galvanized thickened hinge Q235 | |
| Frame color | Painting process Black frame | |
| Floor | Middle floor | 18mm glass magnesium board (does not contain asbestos) |
| Both sides floor | 18mm glass magnesium board (does not contain asbestos) | |
| Floor leather | Floor leather Palm wood | |
| Insulated Wall | Wall panel | 70mm sandwich sandwich board, color roll double-sided 0.25 (wood grain color). Standard sandwich material is EPS |
| Partition | 50mm sandwich panel, color steel plate base plate double-sided 0.25 insulation material as above↑ | |
| Main top and side top | 50mm sandwich panel, color steel plate base plate double-sided 0.25 insulation material as above↑ | |
| Electrical System | Parameters |
1. Standard Australian standard wires; 6² incoming wires, 4² air conditioning sockets, 2.5² ordinary sockets, 1.5² lighting. (Circuits that meet certification requirements can be customized according to the country) 2. Circuit breaker system; 1 2P63A main switch, 1 2P32A/2P20A/2P16 branch leakage protector. 3. Lighting; 6 LED ceiling lights. 4. Sockets: Standard Australian three-hole socket (socket standards can be configured according to customer requirements) |
| Door & Window System | Entrance door | Standard thermally-insulated aluminum doors and windows (double-glazed tempered glass with blue film) open outwards (door frame is black) Size: W1890*H2230 |
| Window | Standard aluminum alloy (double glass, tempered, blue film) sliding window with diamond mesh (window frame is black) 920*920*6 pieces | |
A1: It typically takes 2-3 experienced workers only 1 to 2 hours to fully unfold and set up the structural components of the 20-FT expansion container house, offering an extremely fast installation process compared to traditional buildings.
A2: The house utilizes 70mm sandwich panels (with standard EPS core insulation) along with double-glazed tempered glass for doors and windows. This configuration ensures excellent thermal insulation and keeps energy costs down.
A3: Yes, definitely. While the default configuration is based on Australian standards, we can fully customize the electrical layout, wire sizes, socket styles, and circuit breakers to comply with your local national certification requirements.
A4: Yes. When folded, the width of the container house is compressed to 2200mm, making it highly compact. It fits easily into standard shipping containers for safe, cost-efficient, and convenient global transport.
A5: The main framework is constructed using robust Q235 galvanized square tubes (80*100*2.5MM) and galvanized folding pieces (150*210*2.0MM). It is protected by a premium black painting process for enhanced rust resistance and structural integrity.
A6: The floor features an 18mm glass magnesium board base, which is completely asbestos-free. It is then topped with a high-durability palm wood style floor leather for an aesthetic and durable finish.
